Wacker Neuson G 240

G 230 / G 240 Schematics, Machines with Deep Sea Controller
wc_tx003750gb_FM10.fm
237
27.2
Electrical Schematic Components: G 230 / G 240
Ref. Description Ref. Description
1 Lug safety limit switch 14 Auxiliary stator winding
2 Mechanical lugs 15 Voltage selector switch
3 Main circuit breaker 16 Generator
4 Plug 4 - line voltage inputs 17 Voltage regulator with 4A fuse
5 Plug 5 - current transformer inputs 18 Voltage adjustment rheostat
6 120V GFI receptacle 19 Machine and components
7 120V 20A breaker 20 Exciter rotor windings
8 240V 50A breaker 21 Exciter stator winding
9 Shunt 22 Rotor
10 240V 50A receptacle 23 Rectifier (diodes)
11 Bond bar 24 Main rotor winding
12 Genset controller 25 Main stator windings
13 Stator 26 Exciter
Wire Colors
BLK Black RED Red WHT White ORG Orange
GRN Green TAN Tan YEL Yellow — —
BLU Blue VIO Violet GRY Gray — —
