Mobile Generator
Operation (Basler Controller)
7.4 Overcurrent Condition
Along with engine functions, the genset controller continuously monitors the
current load in each leg. The values for current overload are programmed into the
ECM at the factory and are different for each generator size.
When an overcurrent condition is sensed in any leg, the pre-alarm/shutdown LED
(b) flashes and the LCD displays OVERCURRENT.
If the overcurrent condition persists, the main circuit breaker (a) opens and the
LCD screen changes to OVRLOAD - SET BRKR. This indicates an overload fault.
To clear the overload fault, reset the main circuit breaker. Failing to reset the main
circuit breaker within 5 minutes will cause the machine to shut down. The LCD
screen will then change to OVERLOAD.
7.5 Idle Switch
Location and
description
If equipped, the idle switch (x) is located at the left side of the engine start switch. It
is a two-position switch: Low Idle (turtle), and Rated Speed (rabbit).
The idle switch allows the operator to select the speed of the engine at start-up.
Starting the engine at low idle is recommended when operating this machine in
extremely cold weather. Otherwise, the engine can be started at rated speed.
NOTICE: Disconnect all loads from the engine before starting at low idle.
AUSAUS
APAGADOAPAGADO
ARRETARRET
OFFOFF
REMOTE STARTREMOTE START
FERNSTARTFERNSTART
ARRANQUE REMOTOARRANQUE REMOTO
DEMARRAGE A DEMARRAGE A
DISTANCEDISTANCE
START / LAUFENSTART / LAUFEN
ARRANQUE / MARCHAARRANQUE / MARCHA
DEMARRER / MARCHEDEMARRER / MARCHE
START / RUNSTART / RUN
A
Ø
HZ
V
R
Basler
DIAGNOSTICS
DIAGNOSEN
DIAGNOSTICOS
DIAGNOSTICS
042563
wc_gr010360
a
b
A
Ø
HZ
V
R
Basler
DIAGNOSTICS
DIAGNOSEN
DIAGNOSTICOS
DIAGNOSTICS
AUSAUS
APAGADOAPAGADO
ARRETARRET
OFFOFF
REMOTE STARTREMOTE START
FERNSTARTFERNSTART
ARRANQUE REMOTOARRANQUE REMOTO
DEMARRAGE A DEMARRAGE A
DISTANCEDISTANCE
START / LAUFENSTART / LAUFEN
ARRANQUE / MARCHAARRANQUE / MARCHA
DEMARRER / MARCHEDEMARRER / MARCHE
START / RUNSTART / RUN
x
wc_gr009225
