G 230 / G 240 Schematics, Machines with Basler Controller
wc_tx003749gb_FM10.fm
229
26.10 Electrical Schematic Components
Ref. Description Ref. Description
1 Plug 1 - power and engine sender inputs 5 Idle toggle switch
Ground 6 Remote start / Off / Start/Run switch
Battery - 7 Relay - engine outputs
Battery + 8 Hour meter
Fuel level 9 30A fuse
Sender common 10 10A fuse
2 Plug 2 - contact inputs 11 10A fuse
Regeneration 12 5A fuse
Idle 13 7.5A fuse
Remote start 18 Emergency stop switch
Remote start mode 19 Remote start terminals
Run mode 22 Shunt
Breaker tripped 23 Mechanical lugs
3 Electronic control unit (genset controller) 24 Main circuit breaker
4
Plug 4 - E-stop, CANBUS, contact
outputs
25
Fuel level sender
Emergency stop 26 Lug door interlock switch
Emergency stop 27 Bond bar
Canbus low
28
Shunt trip relay
Canbus high 30 120 Ohm resistor
Shield 33 Terminal strip
Remote annunciator common 49 Toggle switch
Alarm 50 Light
Prealarm — —
Regenerator light — —
Battery + — —
Trip breaker — —
Wire Colors
BLK Black RED Red WHT White ORG Orange
GRN Green TAN Tan YEL Yellow — —
BLU Blue VIO Violet GRY Gray — —
