Watlow PM PLUS™ 6 • 118 • Chapter 10 Appendix
Assembly Definition Addresses and Assembly Working Addresses
Pointer Registers
Assembly Definition Addresses are fixed addresses that define
the parameter stored in "Working Addresses," also referred to as
a pointer. The value stored in these addresses will point to the
Modbus
®
address of a parameter within the PM control.
Working Registers
Assembly Working Addresses are fixed addresses that are
directly related to their associated "Assembly Definition Address-
es" (i.e., Assembly Working Addresses 200 & 201 will assume
the parameter pointed to by Assembly Definition Addresses 40
& 41).
40 & 41 200 & 201
42 & 43 202 & 203
44 & 45 204 & 205
46 & 47 206 & 207
48 & 49 208 & 209
50 & 51 210 & 211
52 & 53 212 & 213
54 & 55 214 & 215
56 & 57 216 & 217
58 & 59 218 & 219
60 & 61 220 & 221
62 & 63 222 & 223
64 & 65 224 & 225
66 & 67 226 & 227
68 & 69 228 & 229
70 & 71 230 & 231
72 & 73 232 & 233
74 & 75 234 & 235
76 & 77 236 & 237
78 & 79 238 & 239
80 & 81 240 & 241
82 & 83 242 & 243
84 & 85 244 & 245
86 & 87 246 & 247
88 & 89 248 & 249
90 & 91 250 & 251
92 & 93 252 & 253
94 & 95 254 & 255
96 & 97 256 & 257
98 & 99 256 & 259
100 & 101 260 & 261
102 & 103 262 & 263
104 & 105 264 & 265
106 & 107 266 & 267
108 & 109 268 & 269
110 & 111 270 & 271
112 & 113 272 & 273
114 & 115 274 & 275
116 & 117 276 & 277
118 & 119 278 & 279
