WEG CFW-10 - Page 46

46
CHAPTER 3 - INSTALLATION AND CONNECTION
Standard Model: B84142 - A20-R
Supply voltage: 250 V, 50/60 Hz
Current: 20 A
Weight: 1 kg (2.2 lb)
Figure 3.15 a) b) - Drawing of the Standard Filter
a) Standard Model: B84142-A20-R (EPCOS)
Standard Model: B84142 - A30-R
Supply voltage: 250 V, 50/60 Hz
Current: 30 A
Weight: 1 kg (2.2 lb)
b) Standard Model: B84142-A30-R (EPCOS)
Terminals 6 mm²
50.8±0.3
6.3 0.8±0.1
40±1
11
20
84
Terminals
6 mm²
40±1
24±1
PE M5 x 20
99
130
4.3±0.1
105
95.2
24±1
16±1
68
Terminals 4 mm²
50.8±0.3
6.3
20
11
0.8±0.1
35±1
4.3±0.1
105
95.2
16±1
24±1
68
±1
84
Terminals
4 mm²
24±1
35±1
PE M5 x 20
121±1
99
±1
±1
±1
Note: Figure dimensions are in mm.
Note: Figure dimensions are in mm.
NOTE!
The declaration of conformity CE is available on the website
www.weg.net or on the CD, which comes with the products.
