45
CHAPTER 3 - INSTALLATION AND CONNECTION
Figure 3.14 c) - Drawing of the footprint / booksize filter
Footprint / booksize Model B84142B22R212 (EPCOS)
Supply voltage: 250 V, 50/60 Hz
Current: 22 A
Weight: 1.4 kg (3 lb)
c) Footprint/booksize Model B84142B22R212 (EPCOS)
Terminals 6 mm
2
Tightgning torque of screw
max. 1.2 Nm
3 x litzwire 4 mm
2
3 x wire and sleeve DIN
46228-A2, 5-10
125
50
5 x 45 º
234
ø
1
1
5.5
179±0.2 221±0.3
5.5
105±0.2
100±0.2
5.5
37.5
7.5
4 x M4 x 7
170 x 5
PE M5 x 12
25
25
Note: Figure dimensions are in mm.
