CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
The P040 parameter indicates the process variable value
(feedback) in the selected scale at P528, which is set according to
the following equation:
P528 =
full scale of used sensor
x 100
P234
Example: Consider the previous example data (pressure sensor of
0 - 25 bar and P234 = 200). P528 must be set to (25/200) x 100 = 12.5.
