CHAPTER 8
CFW-08 OPTIONS AND ACCESSORIES
This Chapter describes the optional devices that can be used internal or
external with the CFW-08 . Table below shows a list of existing optional
devices and the types to which they are applied. Are also given information
about the optional devices and their application.
Name
HMI-CFW08-P
TCL-CFW08
HMI-CFW08-RP
MIP-CFW08-RP
HMI-CFW08-RS
MIS-CFW08-RS
CAB-RS-1
CAB-RS-2
CAB-RS-3
CAB-RS-5
CAB-RS-7.5
CAB-RS-10
CAB-RP-1
CAB-RP-2
CAB-RP-3
CAB-RP-5
CAB-RP-7.5
CAB-RP-10
KCS-CFW08
KSD-CFW08
KMD-CFW08-M1
KFIX-CFW08-M1
KFIX-CFW08-M2
KN1-CFW08-M1
KN1-CFW08-M2
MIW-02
Function
Parallel keypad (HMI)
Over to be inserted in the place of the parallel HMI (when it is
mounted in the inverter or it is remote - kit KMR-CFW08-P).
HMI parallel keypad. For remote use with MIP-CFW08-RP
interface and CAB-CFW08-RP (up to 10m).
Interface for the external parallel keypad (remote) HMI-CFW08-RP
HMI serial keypad. For remote use with MIS-CFW08-RS
interface and CAB-RS (up to 10m). Copy Function.
Interface for the external serial keypad (remote) HMI-CFW08-RS
Cable for the remote serial keypad - cable: 1m
Cable for the remote serial keypad - cable: 2m
Cable for the remote serial keypad - cable: 3m
Cable for the remote serial keypad - cable: 5m
Cable for the remote serial keypad - cable: 7.5m
Cable for the remote serial keypad - cable: 10m
Cable for the remote parallel keypad - cable: 1m
Cable for the remote parallel keypad - cable: 2m
Cable for the remote parallel keypad - cable: 3m
Cable for the remote parallel keypad - cable: 5m
Cable for the remote parallel keypad - cable: 7.5m
Cable for the remote parallel keypad - cable: 10m
RS-232 communication interface (PC, PLC, etc).
RS-485 possible when module MIW-02 is used.
RS-232 PC Communication kit : interface RS-232 (KCS-CFW08),
cable RJ-6 to DB9, 3m long, software “SUPERDRIVE”.
Rail Kit -DIN EN 50.022
Fix Kit -M1
Fix Kit - M2
Kit NEMA 1/IP20 for the connection of the metallic conduit -M1
Kit NEMA1/IP20 for the connection of the metallic conduit -M2
RS-232 to RS-485 conversion module (external).
CFW-08 must be fitted with KCS-CFW08 module.
Models to which
are applied
All
1.6-2.6-4.0-7.0A/
200-240V
1.0-1.6-2.6-4.0A/
380-480V
1.6-2.6-4.0-7.0A/
200-240V
1.0-1.6-2.6-4.0A/
380-480V
7.3-10-16A/
200-240V
2.7-4.3-6.5-10A/
380-480V
1.6-2.6-4.0-7.0A/
200-240V
1.0-1.6-2.6-4.0A/
380-480V
7.3-10-16A/
200-240V
2.7-4.3-6.5-10A/
380-480V
All
WEG Item
Number
417100868
417100881
417100991
417100990
417100992
417100993
0307.7827
0307.7828
0307.7829
0307.7830
0307.7831
0307.7832
0307.7711
0307.7712
0307.7713
0307.7833
0307.7834
0307.7835
417100882
417100875
417100879
417100994
417100995
417100877
417100880
417100543
