INSTALLATION AND CONNECTION
3.3.4 EMC Filters
Characteristics Filter
Table 3.7 - EMC filters characteristics
Filter WEG P/N Rated current Weight
Dimensions
Drawings
(Width x Height x Depth)
FEX1-CFW08 417118238 10A
0.6kg 79x190x51mm Fig. 3.16
FEX2-CFW08 417118239 5A
FS6007-16-06 0208.2072 16A 0.9kg 85.5x119x57.6mm Fig. 3.17
FS6007-25-08 0208.2073 25A 1.0kg
85.5x119x57.6mm Fig. 3.18
FS6007-36-08 0208.2074 36A 1.0kg
FN3258-7-45 0208.2075 7A 0.5kg 40x190x70mm
Fig. 3.19
FN3258-16-45 0208.2076 16A 0.8kg 45x250x70mm
FN3258-30-47 0208.2077 30A 1.2kg 50x270x85mm
TOR1-CFW08 417100895 - 80g
φ
e
=35mm,
Fig. 3.20
h=22mm
TOR2-CFW08 417100896 - 125g
φ
e
=52mm,
Fig. 3.21
h=22mm
Obs.:
1) First environment: environment that includes domestic premises. It
also includes establishments directly connected without intermediate
transformers to a low-voltage power supply network which supplies
buildings used for domestic purposes.
2) Second environment: environment that includes all establishments other
than those directly connected to a low-voltage power supply network
which supplies buildings used for domestic purposes.
3) Unrestricted distribution: mode of sales distribution in which the supply
of equipment is not dependent on the EMC competence of the customer
or user for the application of drives.
4) Restricted distribution: mode of sales distribution in which the
manufacturer restricts the supply of equipment to suppliers, customers
or users who separately or jointly have technical competence in the
EMC requirements of the application of drives.
(source: these definitions were extracted from the product standard
IEC/EN61800-3 (1996) + A11 (2000))
5) This is a product of restricted sales distribution class according to the
product standard IEC/EN61800-3 (1996) + A11 (2000). In a domestic
environment this product may cause radio interference in which case
the user may be required to take adequate measures.
6) The harmonic current emissions defined by the standards IEC/EN61000-
3-2 and EN61000-3-2 / A14 do not apply because the CFW-08 inverter
series are intended for professional applications.
