CFW-08 - QUICK PARAMETER REFERENCE
Display Description Page
E00 Output Overcurrent/Short-Circuit 110
E01 DC Link Overvoltage 110
E02 DC Link Undervoltage 110
E04 Inverter Overtemperature 111
E05 Output Overload (Ixt Function) 111
E06 External Fault 111
E08 CPU Error (Watchdog) 111
E09 Program Memory Error (Checksum) 111
E10 Keypad Copy Function Error 111
E14 Self-tuning Fault 111
E22, E25
Serial Communication Error 111
E26 and E27
E24 Programming Error 111
E28 Serial Interface Watchdog Timeout Error 111
E31 Keypad Connection Fault (HMI-CFW08-RS) 111
E41 Self-Diagnosis Fault 111
2. Fault Messages
3. Other Messages
Display Description
rdy Inverter is ready to be enabled
Sub
Power suplly voltage is too low for the inverter operation
(Undervoltage)
dcbr Inverter in DC braking mode
auto Inverter is running self-tuning routine
copy
Keypad Copy Function in Progress (only available in
the HMI-CFW08-RS) - inverter to keypad
past
Keypad Copy Function in Progress (only available in
the HMI-CFW08-RS) - Keypad to Inverter

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
