WEG CFW08 Vector inverter Plus User Manual

124
CFW-08 OPTIONS AND ACCESSORIES
To install the RS-232 communication kit on the PC, proceed as follows:
- Remove the parallel keypad (HMI-CFW08-P) from the inverter.
- Install the serial communication module RS-232 (KCS-CFW08) in the
place of the keypad.
- Install the software “SUPERDRIVE” in the PC.
- Connect the inverter to the PC through the cable.
- Follow the instruction given by the “SUPERDRIVE”.
8.11 KMD-CFW08-M1
This device must be used when the installation of the inverter on 35mm
rail, according to DIN EN 50.022, is desired
Only available for the models: 1.6-2.6-4.0-7.0A/ 200-240V and
1.0-1.6-2.6-4.0A/380-480V
Figure 8.15 - Inverter with DIN rail kit (KMD-CFW-08-M1)
Section A-A
Front View
Section B-
12
75
129 140
4
64
B
B
A'A
9

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
