WEG CFW08 Vector inverter Plus User Manual

134
CFW-08 OPTIONS AND ACCESSORIES
- IDENTIFICATION
network address;
inverter;
software version.
- CONTROL
general enabling/disabling;
enabling/disabling by ramp;
direction of rotation;
frequency/speed reference;
local/remote;
JOG;
error and fault RESET.
- STATUS RECOGNITION
ready;
Sub;
run;
local/remote;
error;
JOG;
direction of rotation.
- PARAMETER READING
- CHANGE OF PARAMETERS
Typical examples of network use:
PC (master) for the parametrization of one or several inverters at the
same time;
SDCD monitoring inverter variables;
PLC controlling the operation of one or more inverters in a industrial
process.
8.19.2 Interfaces Description
The physical connection between the inverters and the master is performed
according to one of the standards below:
a. RS-232 (point-to-point up to 10m);
b. RS-485 (multipoint, galavanic isolation, up to 1000m);
8.19.2.1 RS-485
This interface permits the linkage of up to 30 inverters to a master (PC,
PLC, etc.), attributing and setting for each inverter an address (1 to 30). In
addition to these 30 addresses, there are two addresses to perform special
tasks:
Address 0: any inverter in the network is inquired, independently of its
address. Only one inverter can be connected to the network (point-to-
point) in order to prevent short-circuits in the line interface.

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
