WEG CFW08 Vector inverter Plus User Manual

140
CFW-08 OPTIONS AND ACCESSORIES
3) Master:
EOT
Reading of the output current from the inverter 10
(supposing the the same was at 7.8A at the moment of the enquiry).
1) Master:
EOT J 0 1 7 0 3 ENQ
P003 Code
addr.10
2) Inverter:
P003 Code
P003=30CH=780=7.8/0.01
addr.10
3) Master:
EOT
8.19.5 Variables and Errors
of the Serial
Communication
8.19.5.1 Basic Variables
8.19.5.1.1 V00 (code 00700)
Indication of the inverter model (reading variable).
The reading of this variable permits the identification of the inverter
type. For the CFW-08 this values is 7, as defined in 8.21.3.7.
8.19.5.1.2 V02 (code 00702)
Indication of the inverter status (reading variable)
Logical status (byte-high)
Error code (byte-low)
where:
Logical Status:
EL15 EL14 EL13 EL12 EL11 EL10 EL9 EL8
J STX 0 1 7 0 3 = 0H 3H 0H CH ETX BCC

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
