WEG CFW08 Vector inverter Plus User Manual

7
CFW-08 - QUICK PARAMETER REFERENCE
Software: V3.9X
Application:
Model:
Serial Number:
Responsible:
Date: / / .
1. Parameters
Parameter Function
Adjustable Range
Factory User
Note Page
Setting Setting
P000 Parameter Access
0 ... 4, 6 ... 999 = Read
0- 72
5 = Alteration
READ ONLY PARAMETERS (P002 ... P099)
P002
Fequency Proportional Value
0 ... 6553 - - 72
(P208xP005)
P003 Motor Current 0 ... 1.5xI
nom
-- 72
P004 DC Link Voltage 0 ... 862V - - 72
P005 Motor Frequency 0.00 ... 99.99, 100.0 ... 300.0Hz - - 72
P007 Motor Voltage 0 ... 600V - - 72
P008 Heatsink Temperature 25 ... 110°C - - 72
P009 Motor Torque 0.0 ... 150.0% - -
Only avaliable
in vector control 72
mode (P202=2)
P014 Last Fault 00 ... 41 - - 72
P023 Software Version x . y z - - 73
P040
PID Process Variable
0 ... 6553 - - 73
(Value % x P528)
REGULATION PARAMETERS (P100 ... P199)
Ramps
P100 Acceleration Time #1 0.1 ... 999s 5.0 73
P101 Deceleration Time #1 0.1 ... 999s 10.0 73
P102 Acceleration Time #2 0.1 ... 999s 5.0 73
P103 Deceleration Time #2 0.1 ... 999s 10.0 73
P104
0 = Inactive
073
S Ramp 1 = 50%
2 = 100%
Frequency Reference
0 = Inactive
1 = Active 1 74
P120 Digital Reference Backup 2 = Backup by P121
(or P525 - PID)
P121 Keypad Reference P133 ... P134 3.00 74
P122 JOG Speed Reference 0.00 ... P134 5.00 74
P124 Multispeed Reference 1 P133 ... P134 3.00 75
P125 Multispeed Reference 2 P133 ... P134 10.00 75
P126 Multispeed Reference 3 P133 ... P134 20.00 75
P127 Multispeed Reference 4 P133 ... P134 30.00 75
P128 Multispeed Reference 5 P133 ... P134 40.00 75
P129 Multispeed Reference 6 P133 ... P134 50.00 75
P130 Multispeed Reference 7 P133 ... P134 60.00 75
P131 Multispeed Reference 8 P133 ... P134 66.00 75
QUICK PARAMETER REFERENCE, FAULT AND STATUS MESSAGES

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
