27
GENERAL INFORMATION
2.5 Receiving and
Storing
NOTE!
The Option field (S or O) defines if the CFW-08 is a standard version or
if it will be equipped with any optional devices. If the standard version
is required, the specification code ends here.
The model number has always the letter Z at the end. For example:
CFW080040S2024ESZ = standard 4.0A CFW-08 inverter, single-phase
at 200...240V input with manual in English.
For the effect of this code, the standard product is conceived as follows:
- CFW-08 with standard control board.
- Degree of protection: NEMA 1 for the models 13 and 16A/380-480V;
IP20 for the other models.
If the CFW-08 is equipped with any optional devices, you must fill out
all fields in the correct sequence up to the last optional device, the
model number is completed with the letter Z. It is not necessary to
indicate the code number 00 for those optional devices that are standard
or that will not be used.
Thus, for instance if the product above is required with NEMA 1 degree
of protection:
CFW080040S2024EON1Z = CFW-08 inverter, 4A, single-phase,
200...240V input, with manual in English language and with kitf for
NEMA 1 degree of protection.
The CFW-08 Plus is formed by the inverter and the control board 1.
Example: CFW080040S2024EOA1Z.
7.0 and 16.0A/200-240V and for all 380-480V models are just available
with three-phase power supply.
A RFI Class A filter (optional) can be installed inside the inverter in
models 7.3 and 10A/200-240V (single-phase) and 2.7, 4.3, 6.5, 10, 13
and 16A/380-480V. Models 1.6, 2.6 and 4.0A/200-240V (single-phase)
and 1.0, 1.6, 2.6 and 4.0A/380-480V can be provided mounted on a
footprint RFI Class A filter (optional).
The listing of the existing models (voltage/current) is shown in item 9.1.
The CFW-08 is supplied in cardboard boxes.
The outside of the packing box has a nameplate that is identical to that
on the CFW-08.
Please check if the CFW-08 is the one you ordered.
Check if the:
CFW-08 nameplate data matches with your purchase order.
The equipment has not been damaged during transport.
If any problem is detected, contact the carrier immedately.
If the CFW-08 is not installed immediately, store it in a clean and dry
room (storage temperatures between –25°C and 60°C). Cover it to
protect it against dust, dirt or other contamination.
