WEG CFW08 Vector inverter Plus User Manual

151
CFW-08 OPTIONS AND ACCESSORIES
... ... ...
... ... ...
... ... ...
Basic Variables
Modbus Address
Decimal Hexadecimal
V00 5000 1388h
V01 5001 1389h
V05 5005 138Dh
Number of the
Basic Variable
Note: All registers (parameters and basic variables) are considered as
holding type registers, referenced from 40000 or 4x, whilst the bits are
referenced from 0000 or 0x.
The status bits have the same functions of the bits 8 to 15 of the logic
status (basic variable 2). These bits are available only for read, thus any
attempt to write command returns error status to the master.
Parameters
Parameter Number
Endereço Modbus
Decimal Hexadecimal
P000 0 0000h
P001 1 0001h
P100 100 0064h
... ... ...
Status Bits
Modbus Address
Decimal Hexadecimal
Bit 0 00 00h
Bit 1 01 01h
Bit 7 07 07h
Bit Number
... ... ...
Commands Bits
Modbus Address
Decimal Hexadecimal
Bit 100 100 64h
Bit 101 101 65h
Bit 107 107 6Bh
Bit Number
Bit Number
Bit 0
Bit 1
Bit 2
Status Bits
Function
0 = Ramp enabling inactive
1 = Ramp enabling active
0 = General enabling inactive
1 = General enabling active
0 = Counter-clockwise direction of rotation
1 = Clockwise direction of rotation

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
