WEG CFW08 Vector inverter Plus User Manual

31
INSTALLATION AND CONNECTION
Inverter
Model
1.6A / 200-240V
2.6A / 200-240V
4.0A / 200-240V
7.0A / 200-240V
7.3A / 200-240V
10A / 200-240V
16A / 200-240V
1.0A / 380-480V
1.6A / 380-480V
2.6A / 380-480V
2.7A / 380-480V
4.0A / 380-480V
4.3A / 380-480V
6.5A / 380-480V
10A / 380-480V
13A / 380-480V
16A / 380-480V
Width L
in
(mm)
2.95
(75)
2.95
(75)
2.95
(75)
2.95
(75)
4.53
(115)
4.53
(115)
4.53
(115)
2.95
(75)
2.95
(75)
2.95
(75)
4.53
(115)
2.95
(75)
4.53
(115)
4.53
(115)
4.53
(115)
5.63
(143)
5.63
(143)
Height H
in
(mm)
5.95
(151)
5.95
(151)
5.95
(151)
5.95
(151)
7.87
(200)
7.87
(200)
7.87
(200)
5.95
(151)
5.95
(151)
5.95
(151)
7.87
(200)
5.95
(151)
7.87
(200)
7.87
(200)
7.87
(200)
7.99
(203)
7.99
(203)
Depth P
in
(mm)
5.16
(131)
5.16
(131)
5.16
(131)
5.16
(131)
5.91
(150)
5.91
(150)
5.91
(150)
5.16
(131)
5.16
(131)
5.16
(131)
5.91
(150)
5.16
(131)
5.91
(150)
5.91
(150)
5.91
(150)
6.50
(165)
6.50
(165)
A
in
(mm)
2.52
(64)
2.52
(64)
2.52
(64)
2.52
(64)
3.98
(101)
3.98
(101)
3.98
(101)
2.52
(64)
2.52
(64)
2.52
(64)
3.98
(101)
2.52
(64)
3.98
(101)
3.98
(101)
3.98
(101)
4.76
(121)
4.76
(121)
B
in
(mm)
5.08
(129)
5.08
(129)
5.08
(129)
5.08
(129)
6.97
(177)
6.97
(177)
6.97
(177)
5.08
(129)
5.08
(129)
5.08
(129)
6.97
(177)
5.08
(129)
6.97
(177)
6.97
(177)
6.97
(177)
7.09
(180)
7.09
(180)
C
in
(mm)
0.20
(5)
0.20
(5)
0.20
(5)
0.20
(5)
0.28
(7)
0.28
(7)
0.28
(7)
0.20
(5)
0.20
(5)
0.20
(5)
0.28
(7)
0.20
(5)
0.28
(7)
0.28
(7)
0.28
(7)
0.43
(11)
0.43
(11)
D
in
(mm)
0.24
(6)
0.24
(6)
0.24
(6)
0.24
(6)
0.20
(5)
0.20
(5)
0.20
(5)
0.24
(6)
0.24
(6)
0.24
(6)
0.20
(5)
0.24
(6)
0.20
(5)
0.20
(5)
0.20
(5)
0.39
(10)
0.39
(10)
Mounting
Screw
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
5/32
(M4)
3/16
(M5)
3/16
(M5)
Weigth
lb
(kg)
2.2
(1.0)
2.2
(1.0)
2.2
(1.0)
2.2
(1.0)
4.4
(2.0)
4.4
(2.0)
4.4
(2.0)
2.2
(1.0)
2.2
(1.0)
2.2
(1.0)
4.4
(2.0)
2.2
(1.0)
4.4
(2.0)
4.4
(2.0)
4.4
(2.0)
5.5
(2.5)
5.5
(2.5)
Degree of
Protection
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
IP20 / NEMA1
NEMA1
NEMA1
Dimensions Fixing base
Table 3.2 - Installation data (dimensions in mm) - Refer to Section 9.1
Figure 3.3 - Mounting procedures for CFW-08
AIR FLOW

WEG CFW08 Vector inverter Plus Specifications

General

Frequency	50/60 Hz
Output Frequency	0-400 Hz
Overload Capacity	150% for 60 seconds
Protection Degree	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Braking	Dynamic braking (with optional braking resistor)
Communication Interface	RS-485 (Modbus RTU)
Ambient Temperature	-10°C to +50°C
Humidity	5 to 95% non-condensing
Cooling Method	Fan Cooled
Dimensions	Varies depending on model (refer to specific model datasheet)
Power Range	0.75-15 kW
Input Voltage	200-240V AC
Storage Temperature	-25°C to 65°C (-13°F to 149°F)
