65
KEYPAD (HMI) OPERATION
Table 5.1 - Incompatibility of parameters - E24
P265=3 (JOG) and other(s) DI(s) ≠ Start/Stop or forward run and reverse or FWD run and REV run
using Ramp #2
P266=3 (JOG) and other(s) DI(s) ≠ Start/Stop or forward run and reverse or FWD run and REV run
using Ramp #2
Two or more parameters among P264, P265 and P266 equal to 1 (LOC/REM)
P265=13 and P266=13 (flying start disable)
P265=10 and P266=10 (reset)
P263=14 and P264≠14 or P263≠14 and P264=14 (3-wire - Start/Stop)
Two or more parameter among P264, P265 and P266 equal to 0 (FWD/REV)
P263=8 and P264≠8 and P264≠13
P263≠8 and P263≠13 and P264=8
P263=13 and P264≠8 and P264≠13
P263≠8 and P263≠13 and P264=13
P263=8 or 13 and P264=8 or 13 and P265=0 or P266=0
P263=8 or 13 and P264=8 or 13 and P231≠2
P221=6 or P222=6 and P264≠7 and P265≠7 and P266≠7 (multispeed)
P221≠6 or P222≠6 and P264=7 or P265=7 or 14 or P266=7
P265=14 and P221≠6 and P222≠6
P221=4 or P222=4 and P265≠5 and P266≠5 (EP)
P221≠4 or P222≠4 and P265=5 and P266=5
P295 incompatible to the inverter model (size and voltage).
P300≠0 and P310= 2 or 3 (DC braking and ride-through active)
P203=1 (PID special function) and P221 or P222=1, 4, 5, 6, 7 or 8
P265=6 and P266=6 (ramp #2)
P221=2 or 3 or 7 or 8 and standard inverter
P222=2 or 3 or 7 or 8 and standard inverter
P265=13 and P266=3 (flying start disable)
P221=4 or P222=4 (reference = P.E.) and P265≠5 and 16 and P266≠5 and 16 (DI3 and DI4 not programmed to P.E.).
P265=5 or 16 or P266=5 or 16 (DI3 or DI4 programmed to P.E.) and P221≠4 and P222≠4 (reference≠P.E.).
P265=6 or P266=6 (DI3 or DI4 programmed to the 2nd ramp) and P263=13 or P264=13 (fwd/rev with 2
nd
ramp).
(3) If the last programmed value in the parameter is not functionally
compatible with other parameter values already programmed, E24 -
Programming Error - will be displayed.
Example of programming error:
Programming of two digital inputs (DI) with the same function. Refer to
Table 5.1 for list of programming errors that can generate an E24
Programming Error.
(4) To allow the reprogramming of any parameter value (except for P000
and P121) it is required to set P000 = 5.
Otherwise you can only read the parameter values, but not reprogram
them. For more details, see P000 description in Chapter 6.
