99
8
TECHNICAL CHARACTERISTICS
8.1 - POWER DATA
Line Voltage:
voltage : + 10%, -15% (with motor power loss)
frequency : 50/60Hz ± 10%
Start Duty: 3 x IN for 30 sec, 10 starts per hour
(Standard Connection) -
3 x IN for 25 sec, 10 starts per hour (Delta Inside
Connection)
Overvoltage category III (EN61010/UL508).
Transient voltages according to overvoltage category III.
8.2 - POWER / CURRENT TABLE
120 120 80 144 475 50 37 75 56 100 75 125 93
170 170 113 204 655 75 56 125 93 125 93 150 112
205 205 137 246 781 85 63 150 112 175 130 220 164
255 255 170 306 986 100 75 175 130 200 149 250 186
290 290 193 348 1112 125 93 200 149 250 186 300 224
340 340 227 408 1292 140 104 250 186 280 209 350 261
410 410 273 492 1544 175 130 300 224 350 261 450 336
475 475 317 570 1780 200 149 340 254 400 298 500 373
580 580 387 696 2157 250 186 400 298 500 373 628 468
670 670 447 804 2508 270 201 450 336 550 410 750 559
800 800 533 960 3051 300 224 550 410 700 522 850 634
950 950 633 1140 3591 400 298 750 559 800 597 1150 858
1100 1100 733 1320 4225 450 336 800 597 900 671 1200 895
1400 1400 933 1680 5305 600 447 1000 746 1200 895 1500 1119
Type Rated Rated Maximum Rated
220V 380V 440V 575V
SSW-03 Current Current Current at. Dissipaded
Plus 3xIN 4.5xIN Cont. Power
@ 30s @ 30s Duty
A A A W HP kW HP kW HP kW HP kW
40ºC
40ºC
8.2.1 Table of Power and Currents for Three Cable Standard
Connection (Ambient Temperature of 40°C (104°F)).
8.2.2 Table of Power and Currents for Three Cable Standard
Connection (Ambient Temperature of 55°C (131°F))
55ºC
55ºC
120 100 67 120 403 40 30 75 56 75 56 100 75
170 145 97 174 565 50 37 100 75 100 75 150 112
205 170 113 204 655 75 56 125 93 125 93 175 130
255 255 170 306 986 100 75 175 130 200 149 250 186
290 290 193 348 1112 125 93 200 149 250 186 300 224
340 290 193 348 1112 125 93 200 149 250 186 300 224
410 380 253 456 1436 150 112 270 201 300 224 400 298
475 475 317 570 1780 200 149 350 261 400 298 500 373
580 500 333 600 1869 200 149 370 276 430 321 550 410
670 550 367 660 2076 225 168 400 298 450 336 600 447
800 620 413 744 2403 250 186 450 336 500 373 700 522
950 800 533 960 3051 300 224 600 447 700 522 850 634
1100 850 567 1020 3325 375 280 650 485 750 559 950 708
1400 1080 720 1296 4153 450 336 800 597 900 671 1200 895
Type Rated Rated Maximum Rated
220V 380V 440V 575V
SSW-03 Current Current Current at. Dissipaded
Plus 3xIN 4.5xIN Cont. Power
@ 30s @ 30s Duty
A A A W HP kW HP kW HP kW HP kW
NOTE!
The maximum, powers indicated in the table above are
based on 3 x IN @ 30s and 10 starts per hour. They are also
based on WEG IV pole standard Motors.
