117

APPENDIX

9.12 - SYMBOLS

Electrical Connection between two signals

Boundary Equipment

Terminals for Connection

Signal Shielding

A + B = C

Coil - relay, contactor

Normally Open Contact (NO)

Normally Closed Contact (NC)

Indicator light

Resistor

Capacitor
