DETAILED PARAMETER DESCRIPTION
6.2- READ PARAMETERS - P71...P77, P82, P96...P99
It indicates the Software Version contained in the CPU
(integrated circuit D1 CCS3.0X)
It indicates the output current of the Soft-Starter in
percentage of the switch (IN - %). (Accuracy of ±10%).
It indicates directly the Soft-Starter current in Ampere.
(Accuracy of ±10%).
It indicates the active power required by the load,
values in kW. (Accuracy of ±10%).
NOTE!
OFF will be displayed when by-pass contactor or energy
save is used.
6.2.1 - P71 - Software
Version
6.2.2 - P72 - Motor
Current
6.2.3 - P73 - Motor
Current
6.2.4 - P74 - Active
Power
6.2.5 - P75 - Apparent
Power
6.2.6 - P76 - Load
power factor
6.2.7 - P77 - Output
voltage
6.2.8 - P82 - Motor
thermal protec-
tion status
It indicates the apparent power required by the
load, values in kVA. (Accuracy of ±10%).
It indicates the load power factor, without considering
the harmonic currents generated by the load switching.
NOTE!
OFF will be displayed when by-pass contactor or energy
save is used.
It indicates the Soft-Starter output voltage about the
load, without carring the Back-EMF from the motor.
NOTE!
When the contactor by-pass is used for current or apparent
power reading, the current transformer must be connected
externally after the by-pass connection.
It indicates the status from motor thermal protection in
percentage (0 ... 250).
Note: 250 is the value of the motor thermal protection
tripping, and display indicates E04.
To Next Page
