TECHNICAL CHARACTERISTICS
8.3 - MECHANICAL
DATA
See figure
Finish: - Electrostatic Epoxy Powder Paint
- Colour: Cover - light-gray - RAL 7032
Cabinet - dark-gray - RAL 7022
8.4 - ELECTRONICS
DATA
Permited mains oscillations:
Voltage: 110/120V or 220/230V 10%
Frequency: 50/60Hz 10%
Control
01 differential input: 0...10Vdc, 0...20mA or
4...20mA, non isolated
Resolution: 10 bits
Programmable functions
Analog
Digital
04 Galvanically isolated input
(optocoupled), 24Vdc
Programmable functions
Inputs
01, non isolated, resolution 8 bits - 0...10V
Programmable functions
Analog
02 relays, NO contact, 250V/1A
Programmable functions
01 relay, NO, NC contact - 250V/1A specific
for faults.
Relay
Outputs
Under/Overcurrent at the output of the Soft-
Starter
Phase fault for the supply
Motor phase fault (motor non connected)
Mains frequency with ± 10% oscillation
Tyristor fault
Inverted phase sequence (programmable)
Overtemperature at the power stage
Overload at the output (I²t).
Extern fault
CPU Error
Programming error
Error the serial interface
Protections
Safety
Serial Interface
Communication
RS 232
8.5 - ELECTRONICS DATA / GENERAL
Method
Voltage variation under load
