DETAILED PARAMETER DESCRIPTION
P53 - Programming of the Digital Input 2
(DI2)
OFF, 1, 2, 3, 4
Possible Values
Factory
Standard
1
6.4.9 - P54 - Programming
of the digital
input 3
This parameter enables the digital input 3 (terminal
X2:3) to operate according to the describe codes:
OFF = without function
1 - "Error Reset" (As described in item 6.4.8).
4 - Three Wire Control = allows control of the Soft-Starter
through digital inputs: DI1 (X2:1) start input and DI2
(X2:2) stop input. According to item 9.3.
6.4.10 -P55 - Program-
ming of the
digital input 4
This parameter enables the digital input 4 (terminal
X2:4) to operate according to the described codes:
OFF = Without Programming
1 - "Error Reset" (As described in Item 6.4.8).
2 - "Extern Error" (As described in Item 6.4.8).
3 - "General Enabling" (As described in Item 6.4.8).
4 - "JOG Function". It enables the Digital Input 4 (DI4), when con-
nected to+24Vdc (X2:5), and enables the SSW-03 Plus to ap-
ply the JOG voltage (P33) to the motor (as described in Item
6.3.14.
NOTE!
For the function direction of rotation, parameter P51 must
be set to "3".
2 - "Extern Error" (As described in Item 6.4.8).
3 - "General Enabling" (As described in Item 6.4.8).
4 - "Direction of rotation". It enables the digital Input 3 (DI3),
when connected to +24Vdc (X2:5), it drives the relay RL1
(as described in item 6.4.6) and realizes the reversal of
the motor direction of rotation with the Soft-Starter. See
Item 9.7 - Typic Application with Reversal.
P54 - Programming of the Digital Input 3
(DI3)
OFF, 1, 2, 3, 4
Possible Values
Factory
Standard
2
