USE OF THE HMI
5
5.2 - USE OF THE
HMI-3P
The HMI-3P is a simple interface wich permits the operation
and the programming of the Soft-Starter.
It permits the following functions:
Display of the Soft-Starter operation status, as well as
the main variables
Error display
Display and changing of the adjustable parameters
Soft-Starter operation through the keys START ("I") and
STOP ("O")
5.2.1 - Use of the
HMI-3P for
Operation
All functions relating to the Soft-Starter operation (enabling
(ON - "I") disabling (OFF "O"); increment/decrement (values/
parameters) can be performed through the HMI-3P. This is
made through standard factory programming of the Soft-
Starter. These functions ON, OFF and Reset can also be
executed individually by means of digital inputs. So it is
necessary to program the parameters relating to these
correspondent functions and inputs.
Find below the key description of the HMI-3P used for
operation, when the Soft-Starter is Standard factory
programmed:
When programmed P61 = On
It functions as "I" (START), "O" (STOP) the motor
The motor accelerates and decelerates according to the set
ramps.
