DETAILED PARAMETER DESCRIPTION
P55 - Programming of the Digital Input
4 (DI4)
OFF, 1, 2, 3, 4
Possible Values
Factory
Standard
OFF
6.4.11 - P56 - Programming
of the analog
output
This parameter enables the analog 8 bits output (X2:8
and X2:9) (Voltage 0...10Vdc - gain adjustable at P57)
and indicates the following magnitudes:
OFF = Without Programming
1 - "Current": proportional to the current that flows through the
switch.
2 - "Voltage" proportional to the SSW-03 Plus output voltage.
3 - "Power Factor": porportional to the power factor of the load
without considering the harmonic currents.
4 - "Thermal motor protection": proportional to the thermal state
of the motor.
6.4.12 - P57 - Scaling
of the Analog
Output
This parameter sets the scaling of the analog output
(X2:8 and X2:9) that is defined by the parameter P56.
NOTE!
With gain 1.00 we will have the following conditions:
P56 = 1 Output: 10 Vdc, when 500% of the IN of the Soft-Starter.
P56 = 2 Output: 10 Vdc when 100% of the UN of the Soft-Starter
output.
P56 = 3 Output: 10 Vdc when the load power factor is equal to
1.00.
P56 = 4 Output: 10 Vdc when the state of the thermal protec-
tion of the motor (P82) is equal to 250%.
P56 - Programming of the Analog
output (8 bits)
OFF, 1, 2, 3, 4
Possible Values
Factory
Standard
OFF
