68
6.3.18 -P41 - Voltage
pulse time at
the start
(Kick Start)
The voltage pulse at the start, when enabled, defines
the time during which this voltage pulse (P42) will be
applied to the motor, so that the motor succeeds to
accelerate the initial moment of inertia of the load
coupled to its shaft, as shown in Figure 6.5.
NOTE!
Use this function only for specific applications, where break
away torque is needed.
Factory
Standard
OFF
min. Range max.
shortest step
OFF, 0.2s 0.1s 2s
P41 - Voltage pulse at the start
(Kick Start)
Operation by two wire digital input (DI1)
Attention:
The SSW controller will not accept a new Start command
during the time, adjusted in P36, elapses after Stop. Identically
to serial interface communication.
NOTE!
1) Use this function only if you need to avoid excessive
starting and stopping.
2) The time counter start after Stop command, with or
without soft stop.
3) The time adjusted in P36 must be greater than the
time adjusted in P04 to this function wok properly.
4) This function doesn’t have action at Jog function.
5) During the reversal of the motor direction, the new
start of the motor only will be realized after time,
adjusted in P36, elapses.
6
DETAILED PARAMETER DESCRIPTION
P02
P41
t (s)
UN
U
P42
P01
Figure 6.5 - Voltage pulse at the start
