116
APPENDIX
9
For the integral motor protection it's recommended to
install one or more thermostats in the motor. If the ther-
mostat is not used, the external input error (DI3) from
SSW-03 Plus must be connected to +Vdc.
Motor fuses are normal.
Install one overload relay to each motor.
The Soft-Starter must be selected for a complete start cycle.
