21
INSTALLATION
3
Type Width Height Depth Fasten. Fasten. Fasten Weight Degree
L H P A B bolt kg Protect.
mm (in) mm (in) mm (in) mm (in) mm (in) (lb)
120A
224 365 244 350 175 (5/16") (37.04) Chassis
(8.82) (14.37) (9.61) (13.78) (6.89) M8 16.8 IP00
170/205A
224 480 257 450 175 (5/16") (44.53) Chassis
(8.82) (18.9) (10.12) (17.72) (6.89) M8 20.2 IP00
255...340A
521 530 315 500 350 (5/16") (92.15) Chassis
(20.51) (20.86) (12.4) (19.68) (13.78) M8 41.8 IP00
410A
521 605 325 575 350 (5/16") (110.20) Chassis
(20.51) (23.81) (12.79) (22.63) (13.78) M8 50.0 IP00
475/580A
521 655 325 625 350 (5/16") (129.60) Chassis
(20.51) (25.78) (12.79) (24.60) (13.78) M8 58.8 IP00
670A
521 705 325 675 350 (5/16") (141.06) Chassis
(20.51) (27.75) (12.79) (26.57) (13.78) M8 64 IP00
800/950A
521 855 345 775 350 (5/16") (158.25) Chassis
(20.51) (33.66) (13.58) (30.51) (13.78) M8 71.8 IP00
1100/1400A
679 1210 431 1110 250/250 (3/8") (396.72) Chassis
(26.73) (47.63) (16.97) (43.70) (9.84/9.84) M10 180 IP00
