31
 We do not recommend the use of motors that are operated
in continuous duty with less than 50% of their rated
current.
The rated motor current must not be smaller than 30% of
the rated current of the Soft-Starter, in order that the
overload protection works properly.
INSTALLATION
3
Cables for the connection within the motor Delta connection,
see table 3.3 and table 3.4.
Recommended application see item 9.9 and 9.10.
9
Type
SSW-03
Plus (A)
120
170
205
255
290
340
410
475
580
670
800
950
1100
1400
Standard Connection
220-440V=Y
X (kA)
10
10
10
10
18
18
18
18
30
30
42
42
85
85
Within the Motor Delta Connection
460-575V=Y
X (kA)
10
10
18
18
18
18
30
30
42
42
85
85
85
85
220-440V=Y
X (kA)
10
18
18
18
18
30
30
42
42
85
85
85
85
100
460-575V=Y
X (kA)
18
18
18
30
30
42
42
42
85
85
85
100
100
125
Table 3.6 - Maximum current capacity of the power supply
The SSW-03 Plus is suitable for use on a circuit capable of
delivering not more than X Arms (see below) symmetrical
amperes, Y volts maximum, when protected by Ultra-fast
Semiconductor Fuses.
The SSW-03 Plus can be installed on power supplies with a
higher fault level provided that adequate protection is
provided by the fuses or circuit breaker.
