Maintenance
Tables for operating materials and filling quantities 9.5
183
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
9.4.2
Leakage check
Check the following components to see if they are tight:
• Check air intake line from air filter to engine.
• Check the hose pipes of the cooling system.
• Check engine oil filter.
• Check fuel lines.
• Check the hose pipes and hydraulic cylinders of the steering system.
• Check the hydraulic system, control valve, lowering brake valves, hy-
draulic hoses and hydraulic cylinders.
• Check hydraulic connections of all control circuits, auto-hitch trailer
coupling, tipper connections.
• Check the hose pipes of the braking system and the tank for the
brake fluid.
• Check front and rear axle
Have defects and leaks replaced by an authorized service center.
9.5
Tables for operating materials and filling quantities
9.5.1
Overview of vehicle fluids and filling quantities
Information
The oil level up to the markings on the measuring rods or check plugs is
binding for the oil filling!
Position Capacity Fluid Specification
Front axle 4.2 l (5,2 l – 30 km/h) Transmission oil SAE 90
GL 5
API GL5 – MIL2105
Rear axle 4.9 l (6,1 l – 30 km/h)
Complete hydraulic system 85 l Hydraulic oil HLP ISO VG 46
Hydraulic oil tank 66 l
Grease lubrication points Multi-purpose grease Water-resistant
Braking system 1.0 l ATF oil
Air conditioning system 1.05 kg Refrigerant R134a
Vehicle fluids engines
NOTICE
Damage to the engine due to incorrect filling quantity or incorrect
specification of vehicle fluids!
If the vehicle can be equipped with different engine types, the filling
quantities and specifications of the vehicle fluids of the engine types may
differ. The type label of the vehicle indicates the engine power in kW.
► Ensure that you are reading the data from the correct table.
9
