Technical data
Weights 12.2
235
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
Item Designation Value in mm
4080T Basic Line
A Overall length with standard bucket 5929
Overall length with pallet forks 6451
B Overall length without attachment 5180
C Center of axle to bucket pin 1394
D Wheelbase 2189
E Rear overhang 1531
F* Height above cab LK115-1 2485
Height above cab LK116-1 2660
H Seat height in cab LK115-1 1507
Seat height in cab LK116-1 1590
J* Overall operating height with standard bucket 5815
Total work height with pallet forks 5504
K* Maximum height from bucket pivot point 5076
L* Load-over height with standard bucket 4651
Load-over height with pallet forks 4823
M* Maximum tilt-out height 4226
N* Maximum reach at M with standard bucket 707
Maximum reach at L with pallet forks 310
O* Scraping depth 126
P* Overall width 1742
Q* Track width 1432
R Width across cab 1188
S* Ground clearance 352
T Maximum radius (depending on bucket width) 4275
U* Radius at outer edge of wheel 3840
V* Inside radius 1948
W Articulation angle 42°
X Rollback angle at maximum lifting height 45°
Y Maximum tilt-out angle 30°
Z Roll back angle at ground 36°
4080T Basic Line : All dimensions with tires 12.5/-20 MPT ET10
*If the rim is different or turned, the dimensions will change.
12.2
Weights
12.2.1
Weight of the vehicle
The weight of the vehicle may vary due to different equipment (e.g. when
the tires are filled with water).
Vehicle Operating weight in kg Permissible total weight in kg
4080T Basic Line 5930 6500
