Commissioning
Setting up the operator station 6.2
79
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
6.1.2
Emergency exit
Fig.53: Emergency exit identification
The right door of the cab is provided as an emergency exit if the left door
is blocked. The right door is marked with the label shown.
6.2
Setting up the operator station
6.2.1
Adjusting the seat
WARNING
Risk of accident when adjusting the seat during operation!
Adjusting the seat during operation may result in an accident, serious in-
jury or death.
► Adjust the seat before commissioning the vehicle.
► Ensure that the levers for seat adjustment are locked into place.
Always adjust the seat to individual needs, e.g. height and posture.
These settings prevent tension and fatigue when working.
Adjust the seat so that all control levers, pedals and switches are easily
accessible while your back is resting against the backrest.
The vehicle is equipped with a seat switch. The vehicle can only be star-
ted and operated when the operator of the vehicle is seated in the seat.
If the operator leaves the seat while driving, the drive system is deactiv-
ated at a speed below 1 km/h. At speeds up to 7 km/h, a warning tone
sounds after five seconds and the drive system is deactivated after ap-
prox. ten seconds. At a speed of more than 7 km/h, the warning tone
sounds continuously.
The vehicle is equipped with a seat switch. The drive system and the
working hydraulics of the vehicle can only be activated when the operator
of the vehicle is seated in the seat. When the operator leaves the seat,
the drive system and hydraulic functions are deactivated after five
seconds, even while driving.
6
