Weidemann Basic line 4080T - Engine, Electrical, and Drive System Specifications

Technical data
Engine 12.3
237
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
12.2.2.2
Load diagrams
5,0
4,5
3,0
3,5
4,0
1,5
2,0
1,0
0,5
2,5
0
-0,5
1,01,52,02,53,03,5
0,5 m
[m]
[m]
1570 kg
1359 kg
1040 kg
930 kg
Fig.220: Working load diagram
12.3
Engine
12.3.1
Engine data
Deutz TCD 2.9
Exhaust-emission level EU level IV
Design Straight diesel engine
Number of cylinders 4
Charging Turbocharger
Type designation TCD 2.9
Displacement 2925cm³
Power at rated speed 55.4kW
74.3PS
Maximum rated speed 2300 rpm
Maximum torque 300Nm at 1600 rpm
Idling speed 900 rpm
Minimum specific fuel consumption 210g/kWh
Fuel injection system Common rail direct injection
Injection system 30° in all directions
12
