Weidemann Basic line 4080T - Page 236

Technical data
12.2 Weights
236
Operator’s Manual | 4080T Basic Line | 1000408123 | 05/2019 | [en]
12.2.2
Payload, bearing load and axle load
The payload and bearing load data refer to criteria in which the vehicle is
located on level and load-bearing ground. If the vehicle is used under
conditions which deviate from these criteria, e.g. on soft or uneven
ground, on slopes or if loads can slip, these conditions must be observed
by the operator.
When the tires are filled with water, the payloads and bearing loads
change.
4080T Basic Line
Weight in kg
Permissible axle loads per axle 4500
Permissible payload with bucket 3282
Permissible bearing load with pallet forks 3569
12.2.2.1
Trailer loads and drawbar load
Ø 38 mm
Fig.218: Automatic trailer coupling
Automatic trailer coupling/auto-hitch trailer coupling
Weight in kg
Permissible trailer weight with braked trailer (max. In-
cline 10%)
8000
Permissible trailer loads with an unbraked trailer (max.
Incline 10%)
750
Permissible drawbar load on trailer coupling 75
Ø 30 mm
Fig.219: Maneuvering coupling
Maneuvering coupling
Weight in kg
Permissible trailer weight with braked trailer (max. In-
cline 10%)
3500
Permissible trailer loads with an unbraked trailer (max.
Incline 10%)
750
Permissible drawbar load on trailer coupling 50
