Monterings- og driftsveiledning Wilo-Control EC/ECe-Booster 647
136>128. Resten blir 136-128=8. Bit 6 til 4 blir 0. Bit 3 blir 1, fordi 8=8. Resten blir 0.
Følgelig blir de resterende bits 2 til alle 0.
13.5 ModBus: Parameteroversikt
Holding register
(Protocol)
Name Data type Scale & unit Elements Access* Added
40001
(0)
Version
communication
profile
UINT16 0.001 R 31.000
40002
(1)
Wink service BOOL RW 31.000
40003
(2)
Switch box type ENUM 0. SC
1. SC...FC
2. SCe
3. CC
4. CC...FC
5. CCe
6. SCe NWB
7. CCe NWB
8. EC
9. ECe
10. ECe NWB
R 31.000
40014
(13)
Bus command timer ENUM 0. -
1. Off
2. Set
3. Active
4. Reset
5. Manual
RW 31.000
40015
(14)
Drives on/off BOOL RW 31.000
40025
(24)
Control mode ENUM 0. p-c
1. dp-c
2. dp-v
3. dT-c
4. dT-v
5. n(TV)
6. n(TR)
7. n(TP)
8. n(TA)
9. n-c
10. fill
11. empty/drain
12. FTS
13. cleans/day
14. cleans/
month
R 31.000
40026
(25)
Current value INT16 0.1 bar
0.1 m
0.1 K
0.1 °C
1 cm
1 min
0.1 h
0.1 psi
R 31.000
40041
(40)
Pump 1 mode ENUM 0. Off
1. Hand
2. Auto
RW 31.000
40042
(41)
Pump 2 mode ENUM 0. Off
1. Hand
2. Auto
RW 31.000
40043
(42)
Pump 3 mode ENUM 0. Off
1. Hand
2. Auto
RW 31.000
