en Disposal
82 WILO SE 2019-07
12 Disposal
12.1 Information on the collection of
used electrical and electronic
products
Proper disposal and appropriate recycling of this product prevents damage to the envi-
ronment and danger to your personal health.
NOTICE
Disposal in domestic waste is forbidden!
In the European Union, this symbol can appear on the product, the packaging or the
accompanying documentation. It means that the electrical and electronic products
in question must not be disposed of along with domestic waste.
To ensure proper handling, recycling and disposal of the used products in question,
please note the following points:
▪Only hand over these products at designated, certified collecting points.
▪Observe the locally applicable regulations!
Please consult your local municipality, the nearest waste disposal site, or the dealer who
sold the product to you for information on proper disposal. Further recycling informa-
tion at www.wilo‑recycling.com.
13 Appendix
13.1 System impedances
NOTICE
Maximum switching frequency per hour
The connected motor determines the maximum switching frequency per hour. Note
the technical data of the connected motor! The maximum switching frequency of
the motor must not be exceeded.
NOTICE
• Depending on the system impedance and the maximum connections/hour of the
connected consumers, voltage fluctuations and/or drops may occur.
• When using shielded cables, attach the shielding to the earth rail on one side of the
switchgear!
• Always have connection carried out by a qualified electrician!
• Observe the installation and operating instructions for the connected pumps and
signal transmitters.
3~400V, 2-pole, direct starting
Power in kW System impedance in
ohms
Connections/h
0.37
2.629 6 … 30
0.55
1.573 6 … 30
0.75
0.950 6 … 18
0.75
0.944 24
0.75
0.850 30
1.1
0.628 6 … 12
1.1
0.582 18
1.1
0.508 24
1.1
0.458 30
1.5
0.515 6 … 12
1.5
0.431 18
1.5
0.377 24
1.5
0.339 30
