Equipment
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
WINDSOR
5•156
• Lift the seat base up until seat and back rest are in a V shape.
• Push down on seat base.
• The booth dinette easily converts into a bed.
• Lift seat cushions to an angled vertical position.
• With a firm grip, lift front edge of the table approximately six inches and
push table leg lock to side.
• Swing the table leg up and lock into a horizontal position.
• Continue lifting table until table stays are clear of retainers. Pull
outward and lower table down.
• Use both seat cushions and one back cushion for a mattress. Leave one
back cushion in a vertical position.
WARNING: Do not occupy the booth dinette or dining
chairs while vehicle is in motion. They are not equipped with
occupant restraint systems. Chairs must be stored in an
enclosed area or secured with tie down straps prior to
setting the motorhome into motion to avoid the risk of
personal injury to motorhome occupants resulting from a
crash or sudden stop.
To use the storage compartment located under the bed, locate and unlock
the bed deck latches. Lift up the bed by the front edge of the mattress plat-
form. Gas struts hold the mattress and platform open. To access the engine
compartment, press down on the button in each latch, open the engine hatch
and secure the latch with the hook provided.
NOTE: Do not over stress gas struts by rapidly opening or
closing the bed access cover. This action can damage the
struts or mounts. In extreme cold gas struts may not hold
the mattress platform in the open position.
The Kwikee Super Slide is an option that is available for use in the storage
compartment bays of your motorhome. This will allow you to slide your pay
load outward to gain easier access.
• The motorhome must be level before opening.
• There are two latch releases: one that you need to lift and hold up, the
other one you will pull outward while pulling on the super slide.
• The maximum weight capacity is 1,000 lbs. Never exceed this amount.
WARNING: The motorhome must be level when sliding the
drawer out of the bay compartment. The drawer can slide
out abruptly and cause bodily harm when the motorhome is
not level.
Sleeper to Sofa
DINETTE BED
CONVERSTION
(Optional)
STORAGE -
UNDER BED &
ENGINE ACCESS
SUPER SLIDE
(OPTIONAL)
