Winkhaus blueMatic EAV4 - Motor housing EAV4+; Cable transition T-KÜ-T1 FT

5107364134
8
EN
blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
8.4 Motor housing EAV4+
Voltage: 24V DC +/-5%
Quiescent current: approx. 32mA
Maximum current: approx. 2000mA
Dimensions: 178 x 50 x 15,5 mm
Weight: approx. 390g
Input (opening signal): Potential-free contact as an impulse
(at least 0.3s length)
Connection:: Plug AMP Tyco, HE14, 6-pole, from Winkhaus
premanufactures
Screw connection: 3 x Countersunk screws DIN965 M4 x 8 T15 LH
(left-hand thread)
WLAN: WLAN frequency band 2.4 GHz
Bluetooth®: Bluetooth® 4.2 LE (frequency 2.4 GHz)
Latch retraction time: 2s (default setting), with EAV4+ adjustable to
max. 60s
8.5 Cable transition T-KÜ-T1 FT
General Specifications
Measurements: Overall length approx. 260 mm
Cross section of wires: 6 x 0.25 mm
Max. voltage: 48V DC
Max. switching current: 2A per connection line/wire
Screw fixing: 3 piece 3 x 20 mm, 1 piece 2.9 x 32 mm
(included in set sash part)
Cable transition T-KÜ-T1 FT sash part
Sash part: • T-KÜ-T1 FT 2 M with 2 m cable + plug for motor
housing
• T-KÜ-T1 FT 3,5 M with 3.5 m cable + plug for
motor housing
• T-KÜ-T1 FT 4,5 M with 4.5 m cable + plug for
motor housing
