blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Notice:
The main bolt must always be unlocked manually using the key.
Opening/unlocking the door from the inside
Possibilities:
• via the button
• via the intercom (floating contact button!)
• via the handle and the key (also possible in the event of a power failure)
4 Operation
4.1 Function day/night
4.2 Locking and unlocking
The day/night function prevents locking in day service mode – to enable easy
keyless access to the door (e.g. for loading/unloading a vehicle standing in front
of the door).
Closing/locking
• When the door is pulled closed, automatic mechanical locking takes place by
means of 2 solid hooks (secured against being pushed back) and the latch in
the main lock housing.
• After proper locking, a beep sounds as standard (only for EAV4+)
• Additional protection is provided by manual locking, in which the bolt in the
main lock housing is extended by turning the key (1 x 360°).
Daytime release function
• Temporary release of the door via mechanically adjustable daytime latch
TaFa, operation similar to an electric strike with daytime release.
