Winkhaus blueMatic EAV4 -  Access control systems

Caution! For the combination of the blueMatic EAV4 / EAV4+
access control system, the Winkhaus power supply T-HT
NETZTEIL 24V DC / 2,5A must not be overloaded with more
than 2.5A! With the combination with frame power supply
T-NETZTEILRAHM. 24V DC the power supply should be
charged max. permanently with 1A and max. 2,5A will be
charged for 2s!
Warning! Cable for external signal at frame power supply is
current (24V DC), do not connect external voltage!
Insulated in delivery state, always INSULATE in the event of a
reduction (e.g. adaptation to the installation situation).
DANGER! The door profile must be grounded properly (secure
the eyelet for earthing securely to the metal profile).
Use cable grommet at 230V cable (2 x included)!
No external voltage on output for external signals.
Notice: The Winkhaus frame power supply 24V DC is intended
for the operation of Winkhaus locking systems. In addition,
small consumers (e.g. finger scanners in the door element) can
also be supplied with this frame power supply unit – up to an
additional power requirement of max. 0.2A and the voltage
requirement must match the frame power supply unit (24V DC).
510736442
2
EN
blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Access control systems ZKS:
• Winkhaus app (no additional wiring required)
• e.g. code keyboards, fingerprint systems (pre-assembled plug & play cable
sets are available for common sash-side access control systems)
Access control systems
