8 Technical specifications
8.1 Power supply unit (mounting on DIN rail)
Primary voltage: 100 - 240V AC; 50/60Hz
Secondary voltage: 24V DC stabilized
Current: 2,5A
Power: 60W
Dimensions (H x B x T): 90 x 53 (= 3 TE) x 58 mm
Weight: approx. 0,3 kg
Installation: mounting on DIN rail
8.2 Frame power supply
Input: 230V AC, 47-63Hz, 0,6A
Output: 24VDC 1,5A (2,5A/2s) BM+/EAV4
Protection rating: IP 20
Temperature range: -10 °C to +55 °C
Earthing of the door frame: Eyelet, screw connection with 4 x 15 mm
Dimensions: Frame part approx. 260 x 24 x 33 mm (H x B x T)
Screw connection: max. 4 x 20 mm screws (max. length due to
cable routing!)
8.3 Motor housing EAV4
Voltage: 24V DC +/-5%
Quiescent current: approx. 18mA
Maximum current: approx. 2000mA
Dimensions: 178 x 50 x 15,5 mm
Weight: approx. 385g
Input (opening signal): Potential-free contact as an impulse
(at least 0.3s length)
Connection:: Plug AMP Tyco, HE14, 6-pole, from Winkhaus
premanufactures
Screw connection: 3 x Countersunk screws DIN965 M4 x 8 T15 LH
(left-hand thread)
Latch retraction time: 2s (default setting)
