Winkhaus blueMatic EAV4 - Motor housing blueMatic EAV4;EAV4+

510736424
2
EN
blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Motor housing blueMatic EAV4/EAV4+
Motor housing for powered unlocking,
with integrated control unit, but without cable
• Scope of delivery: individual motor housing,
for retrofitting mechanical locking systems
autoLock AV4D, AV4 or AV3 
• Variants:
– Motor housing EAV4: standard variant,
without app control
– Motor housing EAV4+: with app control
Motor housing single
T-MOTORKASTEN EAV (V) BL
)

T-MOTORKASTEN EAV (V) BL
)
5096287
T-MOTORKASTEN EAV (V)
SWP
)
(only for STV with black
faceplates)

Attention!
Pay attention to left-handed thread!
)
to retrofit simply screw to the Automatic
locking system autoLock AV4D.
