Notice: The indicated access control systems are based on the
current state of knowledge of current models, which are
however subject to regular development. In addition to finger
scanners, there are other variants depending on the model (e.g.
code keypads, etc.). They are often subject to analogue wiring
– to be checked with the specific access control model and the
relevant documents.
510736469
3
EN
blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
3.6 Non Winkhaus access control system (ACS)
3.6.1 Non Winkhaus access control system ACS general
(frame- and sash side)
3.6.2 Non Winkhaus access control system ACS
fingerprint (sash side)
Prerequisites for installation
• The applied access control system have to be installed into the door sash.
If the blueMatic EAV4/EAV4+ automatic locking system is used for other ac-
cess control systems, note the following points:
• Is recommended the Winkhaus power supply T-HT NETZTEIL 24V DC/2,5A
(Part-no. 2126934) or the frame power supply T-NETZTEILRAHM. 24V DC
1,5A (2,5A/2S) BM+/EAV4 (Part-no. 5083482) to use.
• For details on the voltage supply see also chapter 2, power supply
.
• Ensure that the decontrol signal takes place over a potential-free contact
(Normally open contact, at least 0.3s) when using non-Winkhaus access
control systems.
• If required use a coupling relay for realizing this.
