Figure 3.6.2-1: Wiring blueMatic EAV4 / EAV4+ with "Fingerprint ekey dLine"
(sash side)
white  V DC
brown V
green external opening signal
yellow not used
grey
pink
Assembly -wire blue
motor housing plug
-wire white plug for
access control 
green  external opening signal (unlock)
greypink  only with EAV otherwise
not used potential-free
signal output various
signals adjustable
• Default  door closed 
locked
• alternatively signal for
swing door opener
Notice! max  m extendable
(min  x  mm)
}
EAV
potential-free
signal output
Attention!
Remove jumper
(without a jumper, the
output is potential-free)
 white VDC ()
 brown GND (-)
 green Opening signal
 yellow Opening signal
Connection to the ekey dLine control unit
(ekey plug and cable)
