510736427
2
EN
blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49  369  3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Center keep FRA ... AV ...
Center keep for latch and deadbolt, provided for
retrofitting a T-TAGESFALLE “TAFA” or electric
strike, for PVCu/Vinyl, aluminium and wooden
entrance doors.
Select the respective keeps according to the pro-
file systems in the current program manual (see
program overview keep - Chapter 2 or in the on
-
line STV configurator).
Example: profile Deceuninck Elegant Infinity 76
T-Grt. SL U26-76 ...
Please always do include the following specifica-
tions when placing your order: DIN-right-han-
ded or left-handed
T-PLB HOLZ KT 4934769
Program overview keep Timber group 2
T-PLB KUNSTSTOFF KT 4934767
Program overview keep PVCu
Vinyl
group 2
T-PLB ALUMINIUM KT 4934768
Program overview keep
Aluminium
group 2
