blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Daytime latch "TAFA"
Fold-down daytime latch with mechanical adjustabili-
ty by means via integrated switching lever.
Magnetic trigger for center keep FRA ... AV ...
Magnetic trigger for contact-free magnetic release
for autoLock AV4D/AV4/AV3. Can be retrofitted in
center keeps FRA ... AV ... with magnet hole.
T-G1 MAGNETAUSLÖSER 9 MV K AV3 5014379
T-G1 MAGNETAUSLÖSER 13 MV K AV3 5009111
T-G1 MAGNETAUSLÖSER 9 UMV K AV3 5009109
T-G1 MAGNETAUSLÖSER 13 UMV K AV3 5009110
T-G1 MAGNETAUSLÖSER 13 UMV AV3
908
5034506
T-LF G1 MAGNETAUSLÖSER 7 UMV K
AV3
5053727
Part description
Standard Daytime latch 9-91
T-TAGESFALLE 9/91 TAFA FA STARK RS 5015109
T-TAGESFALLE 9/91 TAFA FA STARK LS 5015108
