Winkhaus blueMatic EAV4 -  Cover for wood, 4 mm airgap;  Screw cover;  Cable transition

510736436
2
EN
blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Cover for wood, 4 mm airgap
T-LB ENDKAPPE STKRNT
HOLZ H R SW

Screw cover
T-SET  X SCHRAUBABDECKUNG
RNTSTK MM SW

Cable transition
Notice: Cannot be used with keeps T-MAGNETCLIP 1,0 EAV4+/
BM+ SB U24X5,5 GR as well as T-MAGNETCLIP 1,5 EAV4+/BM+
SB U24X5,5 GR.
Magnetic clip can be used to optionally cover
the screw holes on the frame power supply unit,
tappet contact and striking plate (with central
screw connection).
Cover for wood, 4 mm air gap, with 12 mm radi-
us for frame part tappet contact or frame power
supply, in packages of 10 pieces in a plastic bag
For power supply to consumers in the door sash, cable transitions (details in the
following text) can be used.
