blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Figure 3.6.2-2: Wiring blueMatic EAV4 / EAV4+ with "Fingerprint ekey dLine
and frame power supply" (sash side)
230V AC
white  V DC
brown V Masse
green external opening signal
yellow not used
grey
pink
green  external opening signal (unlock)
greypink  only with EAV otherwise not used
potential-free signal output various
signals adjustable
• Default  door closed  locked
• alternatively signal for swing door
opener
Notice! max  m extendable
(min  x  mm)
}
EAV
potential-free
signal-output
Notice: The positioning of
frame power supply and
cable transition on the hinge
side is recommended, either
between lower / middle door
hinge or in each case approx.
10 cm above / below the
middle door hinge.
Attention!
Remove jumper
(without a jumper, the
output is potential-free)
 white VDC ()
 brown GND (-)
 green Opening signal
 yellow Opening signal
Connection to the ekey dLine control unit
(ekey plug and cable)
