Specifications
Chapter 1: Introduction
Specifications
Physical Description
The following tables contain specifications of the Integris® 2001 Headwall
System.
Table 1-1. Chase Specifications
Feature Dimension
Depth 5 3/8" (13.65 cm)
Width 13 3/4" (34.93 cm)
Table 1-2. Raceway Specifications
Feature Dimension
Depth 3.937" (10.000 cm)
Width (including end caps) 5' 6" (168 cm) to 9' 3"
(282 mm)
Height 8 7/8" (22.54 cm)
Table 1-3. Medical Gas/Vacuum Manifold
Description Specification
Check valves DISS indexed
Copper tubing American Society of Test-
ing and Materials (ASTM)-
B-819
Inner diameter—oxygen and air tubing ½" (12.70 mm)
Inner diameter—vacuum tubing ¾" (19.05 mm)
Brazing Silver alloy
Minimum melting point for brazing 1000°F (538°C)
Pressure test 150 psi (1034 kPa)
Pressure test certification National Fire Protection
Association (NFPA)-99
and/or contractual docu-
ments
Page 1 - 8 Integris® 2001 Headwall System Service Manual (man148ra)
