Integris® 2001 Headwall System with Chase and Raceway
Chapter 3: Theory of Operation
Integris® 2001 Headwall System with Chase and Raceway
Figure 3-2. AC Voltage Distribution to Chase and Raceway
Communications
Standard power
Emergency power
Medical gases
Communications
Standard power
Emergency power
Raceway ground terminals
Medical
gas area
{
Ground bar
6 AWG reference ground wire
m148_007
Page 3 - 4 Integris® 2001 Headwall System Service Manual (man148ra)
